10-24VDC IP67 Waterproof Microwave Vehicle Detector with 1-6m Detection Range for Barrier Gates

Place of Origin	China
Brand Name	JUTAI
Certification	CE, FCC
Model Number	RD24-6M
Minimum Order Quantity	1
Price	Negotiation
Packaging Details	Cartoon
Delivery Time	5-8 days
Payment Terms	T/T,L/C,D/A,D/P,Western Union,Paypal,MoneyGram,Alipay
Supply Ability	1000 pcs per month

Product Details

Operating Frequency	24.150GHz	Input Voltage	10-24VDC
Relay Contact	1A@24VDC/AC	Relay Control Time	1-6s Adjustable
Operating Temperature	-40℃~+70℃	Waterproof	IP67
Detection Range	1-6m	Specification	11.89.82.6cm
Highlight	10-24vdc microwave traffic detector , 10-24vdc microwave vehicle detector , high sensitivity microwave traffic detector

Leave a Message

Product Description

10-24VDC High Sensitivity Waterproof Microwave Vehicle Detector For Various Barrier Gates

The RD24-6M Barrier Gate Radar Sensor is a high-sensitivity waterproof microwave radar sensor specifically designed for barrier gate applications. This advanced detector ensures safe passage by accurately detecting pedestrians or vehicles during the gate closing process, providing reliable safety protection.

Key Features

Versatile compatibility with straight arm, 90° arm, 180° arm, and fence arm gates
Adjustable detection range from 1 to 6 meters
Multiple detection modes (pedestrian, vehicle, or vehicle-only)
Customizable relay output hold time (1-6 seconds)
High sensitivity for accurate and rapid detection
K-Band microwave technology for reliable performance
Wide coverage with high resolution
Easy installation up to 6 meters (20 feet)
Programmable detection sensitivity and direction
IP65 waterproof rating for outdoor durability

Technical Specifications

Working Frequency	24GHz
Detection Range	1-6 meters
IP Rating	IP65 Waterproof
Power Supply	10-24VDC
Customization	OEM and ODM services available

Applications

This radar sensor activates automatic doors, industrial gates, and traffic barriers with ease. Its versatile mechanical orientation allows for precise positioning to suit various installation setups, making it ideal for parking entry systems, boom barriers, and access control applications.
