Multiple Detection Modes Microwave Radar Sensor For Barrier Gate Safety
Product Details
| Operating Frequency | 24.150GHz | Input Voltage | 10-24VDC |
|---|---|---|---|
| Relay Contact | 1A@24VDC/AC | Relay Control Time | 1-6s Adjustable |
| Operating Temperature | -40℃~+70℃ | Waterproof | IP67 |
| Detection Range | 1-6m | Specification | 11.8*9.8*2.6cm |
| Highlight | multiple detection modes microwave radar sensor,barrier gate safety microwave radar sensor,barrier gate safety microwave radar |
||
Product Description
Multiple Detection Modes Microwave Radar Sensor For Barrier Gate Safety
Product Overview
The RD24-6M Barrier Gate Radar Sensor is custom-built for barrier gates, guaranteeing safe passage by detecting pedestrians or vehicles during gate closure. It seamlessly integrates with various barrier gate types, including straight arm, 90° arm, 180° arm, and fence arm gates.
Key Features
- Versatile Compatibility: Works with straight arm, 90° arm, 180° arm, and fence arm gates
- Adjustable Detection Range: Easily adjust from 1 to 6 meters
- Multiple Detection Modes: Switch between pedestrian and vehicle detection
- Adjustable Relay Output Hold Time: Customize from 1 to 6 seconds
- High Sensitivity: Exceptional accuracy for rapid detection
Technical Advantages
- K-Band Microwave Technology for reliable performance
- Wide Coverage and High Resolution
- Multi-Application Activation for automatic doors and gates
- Easy Installation up to 20 feet (6 meters)
- Versatile Mechanical Orientation
- Programmable Detection Sensitivity
- Direction of Movement Detection
Technical Specifications
| Working Frequency | 24G working Frequency |
|---|---|
| Detection Range | 1-6m Detection Range |
| IP Level | IP65 Water Proof Level |
| OEM Services | OEM and ODM Service can be offered |
Product Images
Application Summary
The RD24-6M Barrier Gate Radar Sensor is a robust solution for barrier gate safety management, offering flexible compatibility, adjustable settings, multiple detection modes, and high sensitivity for ensuring secure passage through barrier gates.
