Long Range UHF Card Reader 15M Coverage With 12dB Antenna Wiegand RS232 485 IP65

Place of Origin	China
Brand Name	JUTAI
Certification	CE
Model Number	PUHF12-8-9R2P
Minimum Order Quantity	1
Price	Negotiation
Packaging Details	Cartoon
Delivery Time	5 - 8 working days
Payment Terms	T/T,L/C,D/A,D/P,Western Union,Paypal,,Alipay
Supply Ability	1000 pieces per month

Product Details

Reading Distance	3-15m	Power Supply	<0.5W
Frequency Range	902-928MHz, 860-868MHz	Antenna	Directional Antenna Technology
Output Interface	Wiegand26/34	PC Interface	RS232/RS485
Card Type/	Is01800-6b, ISO1800-6c (EPC G2)	Waterproof	IP65
Support	Iot UHF Long Range Reader	Specification	45cm45cm 4cm
Highlight	UHF Card Reader 15M Coverage , UHF Card Reader with 12dB Antenna , UHF Card Reader Wiegand RS232 485

Leave a Message

Product Description

Advanced UHF RFID Reader with 15M Coverage

Long-Range UHF Card Reader with 12dB Antenna featuring Wiegand, RS232, RS485 interfaces and IP65 rating for superior access control performance.

Product Overview

The Advanced UHF RFID Reader with Cutting-Edge Encryption Technology (PUHF12-8-9R2P) represents the pinnacle of RFID engineering from Shenzhen Jutai Comm Co., Ltd. Operating within 860-868MHz and 902-928MHz frequency bands, this reader delivers exceptional long-range Wiegand reading performance, reaching distances up to 15 meters under optimal conditions while accounting for on-site interference and card reading angles.

Technical Specifications

Operating Frequency

860-868MHz and 902-928MHz (adjustable for regional compliance)

Card Compatibility

ISO18000-6B/6C (EPC GEN2) passive RFID cards

Antenna Type

Circular polarization/linear polarization orientation

Max Output Power

Adjustable up to 30dBm

Reading Range

1 to 12 meters (depending on antenna configuration)

Output Interfaces

Wiegand 26/34, RS232, RS485

PC Connectivity

RS232 interface

Waterproof Rating

IP65 certified

Operating Temperature

-25°C to +70°C

Installation

U-shaped pole mounting

Key Features & Advantages

Exceptional 15-meter reading range for superior coverage and convenience
Independent stand-alone capability with large offline storage capacity
Expert engineering with bespoke protocols and customized solutions
Cutting-edge encryption technology for precise one-to-one identification
Flexible interface compatibility (Serial Port and Wiegand)
IP65-rated weatherproof PET material housing for outdoor durability
Effortless installation on U-shaped poles
Enhanced security with advanced anti-cloning protection

Wire Configuration

Wire Color	Function
Red	DC+ 9-12V
Blue	Wiegand Data 1
Light Pink	RS485 A+
Brown	TXD (RS232)
Black	0V (Ground)
Green	Wiegand Data 0
Yellow Green	RS485 B-
White	RXD (RS232)
Black	0V Ground
Yellow	Short Circuit to Loop Signal
