Developed by Shenzhen JUTAI COMM Co., Ltd., the RVP42-7M is an advanced motion detection device engineered for industrial automatic doors. Designed for high-traffic environments such as high-speed doors, cold storage doors, garage doors, and loading dock doors, this sensor utilizes microwave Doppler radar technology to accurately identify the movement trajectories of both vehicles and pedestrians. It filters out invalid lateral interference, enabling contactless door control and enhancing safety and traffic efficiency in industrial settings.
-
Dual Relay Output Configuration
- Supports Normally Open (NO) and Normally Closed (NC) modes, ensuring seamless compatibility with diverse industrial door control systems for flexible signal transmission.
-
Dual Control Adjustment Design
- Remote Control: Enables quick power activation and basic parameter setup within 30 minutes of operation.
- Bluetooth Connectivity: Allows fine-tuning of sensitivity and detection parameters via a mobile app, adapting to different door types and traffic conditions.
-
Directional Motion Sensing Technology
- Uses trajectory analysis algorithms to precisely determine movement direction, minimizing false triggers and enhancing safety in high-traffic zones.
-
Cross-Traffic Masking Technology
- Intelligently filters out lateral movements (e.g., passing forklifts, side pedestrians), responding only to oncoming targets (vehicles/pedestrians) to reduce unnecessary door operations.
-
Adjustable Sensitivity Levels
- Offers multi-level sensitivity adjustment to adapt to varying traffic speeds and densities, ensuring reliable detection in complex industrial environments.
-
Wide-Range Installation Flexibility
- Can be mounted at heights between 2m and 9m, suitable for small garage doors up to large-scale loading dock systems.
| Parameter |
Specification |
| Emission Frequency |
24.125 GHz |
| Emission Power |
<20 dBm |
| Operating Voltage |
12V–36V DC |
| Operating Current |
<100 mA |
| Maximum Detection Speed |
25 km/h |
| Detection Range |
Up to 7 meters |
| Temperature Range |
-30°C to +60°C |
| Humidity Range |
0%–95% (non-condensing) |
| Protection Level |
IP65 (dustproof and waterproof) |
| Relay Output |
24VDC @ 1A / 125VAC @ 0.5A |
| Cable Length |
7 meters |
| Weight |
630g |
| Dimensions (Incl. Bracket) |
164mm × 111mm × 94.5mm |
The RVP42-7M employs microwave Doppler radar technology to detect motion. It continuously emits 24.125 GHz microwave signals that reflect off moving objects (e.g., vehicles, pedestrians). The sensor analyzes frequency shifts in reflected signals to determine motion direction. Advanced algorithms distinguish between vehicles and pedestrians while ignoring lateral movements, providing accurate data to door control systems.
- High-Speed Industrial Doors: Ideal for factories, warehouses, and distribution centers requiring rapid door operation.
- Cold Storage Doors: Reduces energy loss by triggering door movement only when necessary, maintaining temperature control.
- Garage Doors: Enables safe, contactless access for vehicles and personnel with motion-activated operation.
- Loading Dock Doors: Enhances safety and workflow efficiency by accurately detecting vehicles and optimizing traffic flow.
- Commercial Garage Systems: Improves vehicle access control and operational efficiency in commercial settings.
- Enhanced Safety: Accurately differentiates between vehicles and pedestrians to reduce accident risks.
- Energy Efficiency: Minimizes unnecessary door openings, cutting energy consumption and operational costs.
- Flexible Installation: Adaptable to various heights and environments, from low-traffic to high-speed industrial settings.
- Remote Configuration: Simplifies setup and maintenance via remote control or Bluetooth app.
- Durable Design: IP65-rated dust and water resistance ensures reliability in harsh industrial environments.
The RVP42-7M Microwave Motion Radar Sensor sets a new standard for industrial door automation. With features like directional motion detection, Bluetooth-enabled adjustments, and robust environmental resistance, it delivers reliable, efficient, and energy-saving door control across diverse applications. Its versatile design and ease of integration make it an essential component for modern industrial door systems.
