Detecting Forklift Motion Sensors For Industrial High-Speed Doors
| Place of Origin | China |
|---|---|
| Brand Name | JUTAI |
| Certification | FDA, E-MARK, CE, ISO, FCC, RoHS, DOT, ASTM, AS/NZS, CCC, GS |
| Model Number | RVP42-7M |
| Minimum Order Quantity | 1 |
| Price | Negotiation |
| Packaging Details | Cartoon |
| Delivery Time | 5-8 days |
| Payment Terms | T/T,L/C,D/A,D/P,Western Union,Paypal,,Alipay |
| Supply Ability | 1000 pieces per month |
Product Details
| Output Type | 1 Relay Output. | Power Supply | 12-24VADC |
|---|---|---|---|
| Antenna Frequency | 24.125GHz | Detection Height | 3m To 7m |
| Package Size | 28.00cm * 13.00cm * 10.00cm | Function | Forklift People Distinguish |
| Waterproof | IP65 | Working Temperature | -30~70℃ |
| Setting | Bluetooth APP | ||
| Highlight | industrial door motion sensor,forklift motion sensor for high-speed doors,industrial high-speed door motion detector |
||
Product Description
Detecting Forklift Motion Sensors For Industrial High-Speed Doors
JUTAI RVP42-7M Industrial Motion Sensor 24GHz Radar Vehicle Pedestrian Detection IP65 7m Cable
Product Overview
The JUTAI RVP42-7M is a high-performance industrial motion sensor designed for precision detection in industrial and commercial environments. Leveraging 24.125GHz Doppler radar technology with a planar module, it efficiently detects vehicles and pedestrians, while offering advanced lateral motion filtering to reduce false triggers.
Ideal for industrial doors, garage doors, cold storage doors, and road gates, this sensor ensures reliable operation even in harsh conditions, backed by an IP65 protection rating and a wide temperature range of -30°C to +60°C.
With flexible mounting heights (2m to 7m) and adjustable sensitivity, it adapts to diverse scenarios—from separating vehicle and pedestrian movement to monitoring bidirectional traffic. The 7m cable, robust aluminum-polycarbonate housing, and 1A relay output (supporting max 125V AC/60V DC) further enhance its durability and functionality, making it a trusted choice for industrial security and automation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Technology | Doppler radar with planar module |
| Emission Frequency | 24.125 GHz |
| Transmission Power | <20 dBm |
| Working Voltage | 12-36V ADC |
| Working Current | <100 mA |
| Temperature Range | -30°C to +60°C |
| Relative Humidity | 0%-95% (non-condensing) |
| Mounting Height | 2m to 7m |
| Relay Output | Defaults NO (NC optional) |
| Max Switching Voltage | 125V AC / 60V DC |
| Max Switching Current | 1A |
| Housing Material | Gray anodized aluminum with polycarbonate |
| Size | 164mm × 111mm × 94.5mm |
| Weight | 630g |
| Protection Rating | IP65 |
| Max Detection Speed | 25 km/h (vehicles) |
| Cable Length | 7m |
Key Features
- Dual Detection Capability: Identifies both vehicles and pedestrians with adjustable modes for forward, backward, or bidirectional movement.
- Lateral Motion Filtering: Reduces false alarms from cross-moving objects via adjustable filtration levels.
- Harsh Environment Resistance: IP65 rating and wide temperature/humidity tolerance ensure reliability in industrial settings.
- Flexible Installation: Adaptable to 2m-7m mounting heights with easy wiring and vibration-resistant design.
- Durable Build: Robust housing and 7m cable for long-term, low-maintenance operation.
Perfect for automating access control and enhancing safety in industrial facilities, parking lots, and logistics hubs.
