Smart Gate Controller WiFi/4G Enabled Remote Access Control for Automatic Doors Barriers
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Relay Output | 4 Way | Relay Input | 3 Way |
|---|---|---|---|
| Communicate | WiFi/4G | Operating Temperature Range | -30 To 80 ℃ |
| Intelligent Safety Warning | Double - Notification For Abnormal Events (APP Pop - Up Alarm + Detailed Email Report); Physical Protection Linkage (forced Door Opening Triggers Alarm And Camera Automatically Takes Evidence) | Operation Counting And Health Diagnosis | Full - Cycle Statistics Of Device Opening And Closing Times And Running Duration; Maintenance Warning System With Threshold Triggering And Maintenance Report Generation |
| Highlight | Smart gate controller with WiFi,4G enabled remote access control,Automatic door barrier opener |
||
Product Description
Product Description:
The JUTAI Smart Gate Controller is a cutting-edge WiFi/4G enabled access control solution that brings smart automation to gates, barriers, and doors. Designed for both residential and commercial applications, this JUTAI-branded controller allows users to remotely operate gates, sliding doors, and barriers via a user-friendly mobile app.
Key Features:
-
WiFi & 4G Dual Connectivity – Ensures uninterrupted remote control even when WiFi is unavailable
-
Multi-Device Control – Supports up to 4 relay outputs for gates, lights, and smart home devices
-
Real-Time Monitoring – HD camera integration for live video feeds and two-way audio communication
-
Smart Alerts & Logs – Get instant notifications for unauthorized access or system events
-
Industrial-Grade Durability – Operates in -10°C to 60°C environments, perfect for outdoor installations
-
RS485 Communication – Adjust settings for industrial automation equipment
Applications:
Residential Use:
-
Smart sliding doors (garage, patio, main gate)
-
Home automation (lights, curtains, AC units)
-
Package delivery access (temporary unlock via app)
Commercial & Industrial Use:
-
Barrier gates (parking lots, toll booths)
-
Turnstiles & high-speed doors (office buildings, warehouses)
-
Fleet logistics (loading bay door control)
Technical Specifications:
-
Model: GL-WLAN-01
-
Power Supply: DC 12V 1A (5V customizable)
-
Connectivity: WiFi + BLE + 4G (optional)
-
Relay Outputs: 4 channels (3 shared COM, 1 independent)
-
Operating Temp: -10°C to 60°C
-
Dimensions: 96.5 x 50 x 31.4mm
Why Choose JUTAI?
-
All-in-One Control – Manage gates, barriers, and smart devices from a single app
-
Secure & Encrypted – End-to-end encryption protects against hacking
-
Easy Installation – No professional setup required
Technical Specifications:
|
Parameter |
Details |
|---|---|
| Model | GL-WLAN-01 |
| Power Supply | DC 12V 1A (5V customizable) |
| Load Capacity | DC 30V/1A, AC 125V/1A |
| Connectivity | WiFi + BLE + 4G (optional) |
| Protocols | MQTT, RS485, OTA (Over-The-Air updates) |
| Relay Outputs | 4 channels (3 shared COM, 1 independent) |
| Digital Inputs | 3 non-isolated interfaces |
| Dimensions | 96.5 x 50 x 31.4mm |
| Camera Support | HD streaming, night vision, motion detection |
