Commercial Smart Gate Solution with Live View History Log and Multi User Sharing
| Place of Origin | China |
|---|---|
| Brand Name | GateLink |
| Model Number | GL-WLAN |
| Document | GateLink WIFI APP Controlle...er.pdf |
| Minimum Order Quantity | 1 |
| Price | Negotiation |
| Packaging Details | Cartoon |
| Delivery Time | 5 - 8 working days |
| Payment Terms | T/T,L/C,D/A,D/P,Western Union,Paypal,,Alipay |
| Supply Ability | 1000 pieces per month |
Product Details
| Relay Output | 4 Way | Relay Input | 3 Way |
|---|---|---|---|
| Communicate | WiFi/4G | Operating Temperature Range | -30 To 80 ℃ |
| Intelligent Safety Warning | Double - Notification For Abnormal Events (APP Pop - Up Alarm + Detailed Email Report); Physical Protection Linkage (forced Door Opening Triggers Alarm And Camera Automatically Takes Evidence) | Operation Counting And Health Diagnosis | Full - Cycle Statistics Of Device Opening And Closing Times And Running Duration; Maintenance Warning System With Threshold Triggering And Maintenance Report Generation |
| Highlight | Live View History Log Smart Gate,Commercial Smart Gate Solution,Multi User Smart Gate Solution |
||
Product Description
Commercial Smart Gate Solution with Live View History Log and Multi User Sharing
System Overview
The JUTAI GateLink Commercial Smart Gate Solution is a professional access control system tailored for commercial scenarios, integrating real-time HD live view, detailed history logs, multi-user sharing, and hierarchical management. By combining the GL-WLAN-01 smart controller with high-performance monitoring cameras, it connects to the JUTAI Cloud via WiFi + BLE dual networks, enabling administrators to remotely manage gates, monitor entrances, and share access rights efficiently.
Designed for commercial buildings, industrial parks, shopping malls, and chain stores, it balances security, convenience, and operational efficiency—becoming a reliable intelligent partner for commercial access management.
Core System Components & Technical Parameters
Main Controller (Model: GL-WLAN-01)
| Parameter | Specification |
|---|---|
| Operating Voltage | DC 12V 1A (5V version customizable) |
| Load Capacity | DC 30V/1A, AC 125V/1A |
| Network Connectivity | WiFi + Bluetooth Low Energy (BLE) |
| Communication Protocol | MQTT, supports OTA (Over-The-Air) remote updates |
| Relay Output | 4 channels (3 share common terminal, 1 independent) |
| Digital Input Interfaces | 3 non-isolated (for alarms, limit switches) |
| Expansion Interface | 1x RS485 (for system extension) |
| Dimensions (L×W×H) | 96.5 x 50 x 31.4 mm |
| Compatible Platforms | iOS (App Store), Android (Google Play, AppGallery), PC management software |
| Key Commercial Functions | Multi-user permission control, access history logging, device sharing |
HD Monitoring Cameras
| Parameter | GL-200H26-IR (Bullet Camera) | GL-R300H265-IR (360° Dome Camera) |
|---|---|---|
| Resolution | 2MP (1920*1080P) | 3MP (2304*1296) |
| Lens Specification | 3.6mm @F2.0 (M12 interface) | 2.8mm @F2.0 (M12 interface) |
| Night Vision | 6 IR LEDs, 20-30m range, IR-CUT day/night conversion | Infrared night vision (0 Lux usable) |
| Video Compression | H.265AI (reduces bandwidth usage) | H.265AI |
| Audio Function | Supports G711a audio compression | Built-in audio input/output |
| Protection Level | IP66 (dustproof + waterproof) | IP67 (dustproof + waterproof) |
| Power Supply | DC 12V ±10%, max 4W | DC 12V 2A, max ≤3W |
| Intelligent Alarms | Motion detection, video loss, network disconnection | Motion detection, video loss |
Key Functional Advantages
Real-Time HD Live View & Two-Way Intercom
- 24/7 clear monitoring: Capture high-definition images day and night, with infrared night vision ensuring visibility in low-light or dark commercial environments
- Instant two-way audio: Communicate with visitors, delivery personnel, or on-site staff remotely via the APP
- Multi-camera support: Connect multiple cameras to a single controller, enabling split-screen viewing of multiple entrances
Comprehensive History Log & Data Tracking
- Detailed access records: Log all gate operations, including operator, operation type, time, and access method
- Cycle count statistics: Record gate opening/closing cycle counts for maintenance planning
- Exportable logs: Download and export history logs in batches for commercial compliance
Flexible Multi-User Sharing & Permission Control
- Hierarchical user management: Assign 3-level permissions (super admin, operator, visitor)
- Device sharing: Share gate control rights with employees or partners via the APP
- Temporary authorization: Generate time-limited access codes for temporary visitors
Commercial-Oriented Value-Added Features
- Built-in advertising platform: Display commercial promotions and brand ads in the APP
- Security alarm integration: Connect to commercial alarm systems for instant notifications
- Stable dual-network connection: WiFi ensures remote management, BLE supports on-site control
Easy Installation & Scalable Expansion
- Simple wiring: Connect to existing commercial gate motors via relay outputs
- Plug-and-play setup: Complete installation in minutes, reducing operational downtime
- Flexible expansion: Add new controllers or cameras as business scales
Application Scenarios
- Commercial Office Buildings: Remote management of main entrances, staff doors, and parking barriers with employee APP access
- Industrial Parks & Warehouses: Control access to loading docks and restricted zones with integrated alarm systems
- Shopping Malls & Retail Stores: Manage storefront doors and parking gates with promotional ad capabilities
- Chain Stores & Franchises: Centralized management of multiple branch store gates with unified oversight
- Logistics & Distribution Centers: Secure access for delivery drivers with temporary access and tracking
Why Choose JUTAI Commercial Smart Gate Solution?
- Commercial Efficiency: Multi-user sharing and hierarchical management reduce administrative workload
- Security & Traceability: Comprehensive history logs ensure full traceability of access events
- Value-Added Revenue: Built-in advertising platform creates new income streams
- Stable & Reliable: Dual-network connectivity and industrial-grade hardware for high-traffic environments
- Scalable & Adaptable: Supports system expansion from single gates to multi-location management
