Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side

  • Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side
  • Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side
Place of Origin China
Brand Name JUTAI
Certification CE
Model Number IR-20
Minimum Order Quantity 1
Price Negotiation
Packaging Details Cartoon
Delivery Time 5 - 8 working days
Payment Terms T/T, L/C, D/A, D/P, Western Union, Paypal, , MoneyGram, Alipay
Supply Ability 1000 pieces per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
IP Rating IP65 HS Code 8531901000
Package Size 12.00cm * 11.70cm * 4.30cm Package Gross Weight 0.150kg
Detection Type Photon Detector Type Wired
Highlight

IP65 Infrared Beam Photocell Sensor

,

Two Groups Infrared Beam Photocell Sensor

,

30m Infrared Beam Photocell Sensor
Leave a Message
Product Description
Product Description:

  1. Introduction:
    • The JUTAI IR-20M Infrared Photocell is a high-performance sensor designed for various applications, including outdoor use in barrier gates. It rapidly detects interruptions in the infrared beam and triggers a relay switch signal.
  2. Advantages:
    • Solitary Beam Detectors: Commonly used in automated sliding doors, shutter doors, garage doors, windows, and more.
    • Integrated Transmitter and Receiver: Each unit has a transmitter, receiver, and integrated amplifier to counter external light interference.
    • Reliable Detection Range: Offers a reliable detection range of 2 - 20 meters even at a low installation height (20 - 40cm above the ground).
    • IR - 20 Self - Detection Functionality: Specifically designed for sliding doors, with self - detection capabilities for enhanced safety.
    • Consistent Performance: Maintains consistent detection range in adverse weather conditions, and the IP65 waterproof design ensures durability in outdoor environments.
    • Comprehensive Support: Comes with an English Usage Manual with illustrated diagrams for easy installation and configuration.
  3. Parameters (Table):
    Parameter Details
    Power supply 12/24(VAC/VDC)
    Max.Range up 20Meters(indoor or outdoor)
    Opera temperature -10 - +60°C
    Max.TX working current 25mA
    Max. RX working current 35mA
    Max. Relay contact Max 500mAe48Vac/dc
    IP rate Ip55
  4. Summary:
    • The JUTAI IR - 20M Infrared Photocell is a versatile and reliable sensor that provides enhanced security and convenience. It is suitable for a wide range of applications, including parking barriers, pedestrian gates, vehicle gates, and anti - burglar detection for windows, doors, and passageways. With its reliable performance and durable design, it is an excellent choice for various security systems.

Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 0

 Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 1


Technical parameter

Feature Specification
Power Supply 12-24VAC/VDC
Max. Range 20 Meters
Operating Temperature -10 to +60°C
Max. TX Working Current 25mA
Max. RX Working Current 35mA
Max. Relay Contact 500mA at 48VAC/VDC
IP Rating IP65 with rubber





Gate Opener Manufacturing Infrared Sensor Gate Photocell for Door
Connection Details of JUTAI IR-20
Gate Opener Manufacturing Infrared Sensor Gate Photocell for Door



Gate Opener Manufacturing Infrared Sensor Gate Photocell for Door


Installation
Experience top-tier reliability with the JUTAI IR-20 20 meters wired infrared photocell. Boasting an exceptionally stable and dependable detection distance, our infrared lamps utilize renowned German brands to ensure consistent distance and light resistance. Moreover, our relays feature Japan's Omron brand, guaranteeing compatibility with various door operator brands. Utilizing Surface Mount Technology (SMT) in patch production, we uphold stringent quality standards to ensure the accuracy and consistency of batch production. Trust in the unparalleled quality of our high-quality photo eye for your security and convenience needs.
Gate Opener Manufacturing Infrared Sensor Gate Photocell for Door
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 6
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 7
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 8
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 9
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 10
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 11
Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 12

JUTAI Photocell Beam Sensors Ordering Information
After several years of precipitation and development, we have developed a full range of infrared product groups, ranging from 20 meters wired model, to 30 meters wireless model, 7 meters reflected infrared sensor, and Curtain Photocell groups. For specific information, please refer to our ordering information list.
Gate Opener Manufacturing Infrared Sensor Gate Photocell for Door

Infrared Beam Photocell Sensor 30m IP65 Waterproof Can Work In Two Groups Side By Side 14
